APC BVX700LI uninterruptible power supply (UPS) Line-Interactive 0.7 kVA 360 W 4 AC outlet(s)

Access monitoring
Detect access by unauthorized personnel via door switch.

Transformer-block spaced outlets
Protect equipment with input transformer blocks without blocking access to other receptacles.

Sleek design
Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.

Cold-start capable
Provides temporary battery power when the utility power is out.

Boost Automatic Voltage Regulation (AVR)
Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.

Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Advanced Safety Features
Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.

Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Battery backup and surge protection
Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.

Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes.

LED Indicators
Provide easy-to-read status of the unit and utility power conditions.

Audible alarms
Provides notification of changing utility power and UPS power conditions

Power
Output voltage regulation	10%
Output frequency regulation	0.5 Hz
Input power factor	0.51
Output power	360 W
Input operation voltage (min)	170 V
Input operation voltage (max)	280 V
Output operation voltage (min)	230 V
Output operation voltage (max)	230 V
Surge energy rating	273 J
Output power capacity	0.7 kVA
Performance
Audible alarm modes	Alarm when on battery, Battery replacement, Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Sine
Automatic Voltage Regulation (AVR)	Yes
Response time	6 ms
LED indicators	Yes
Surge protection	Yes
Noise level	40 dB
Audible alarm(s)	Yes
Features
Output frequency	50/60 Hz
Audible alarm modes	Alarm when on battery, Battery replacement, Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Sine
Output voltage regulation	10%
Output frequency regulation	0.5 Hz
Automatic Voltage Regulation (AVR)	Yes
Input power factor	0.51
Response time	6 ms
Output power	360 W
Input operation voltage (min)	170 V
Input operation voltage (max)	280 V
Output operation voltage (min)	230 V
Output operation voltage (max)	230 V
Surge energy rating	273 J
Surge protection	Yes
Noise level	40 dB
Audible alarm(s)	Yes
Output power capacity	0.7 kVA
Input frequency	50/60 Hz
Ports & interfaces
SmartSlot	No
AC outlets quantity	4 AC outlet(s)
AC outlet types	C13 coupler
Power plug	C14 coupler
SmartConnect port	No
Battery
Battery life (max)	2 year(s)
Battery voltage	12 V
Battery capacity	7 Ah
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	8 h
Cold start	Yes
Design
International Protection (IP) code	IP20
Form factor	Compact
LED indicators	Yes
Product colour	Black
Certification	CB, CE, EN/IEC 62040-1, EN/IEC 62040-2
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 40 °C
Operating relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 3000 m
Technical details
Output frequency	50/60 Hz
Harmonized System (HS) code	85078000
Certificates
Certification	CB, CE, EN/IEC 62040-1, EN/IEC 62040-2
Packaging content
Cables included	Input power cable
Manual	Yes
Management card included	No
Weight & dimensions
Package width	222 mm
Package depth	346 mm
Package height	142 mm
Weight	4.5 kg
Width	31 mm
Package weight	4.5 kg
Height	98 mm
Depth	138 mm
Packaging data
Cables included	Input power cable
Manual	Yes
Package width	222 mm
Package depth	346 mm
Package height	142 mm
Package weight	4.5 kg
Management card included	No
Logistics data
Harmonized System (HS) code	85078000
