What it is
The Zyxel USG-LITE 60AX is a wired router designed for small office or branch environments. It supports Ethernet LAN speeds up to 2.5 Gbit/s and can handle up to 20,000 concurrent connections.
Who it's for
This router suits organisations needing reliable, faster-than-gigabit LAN speeds with basic security features like guest access and port forwarding. It’s a fit where wired connections and straightforward traffic management are priorities.
Why it's good
It supports 2.5GBase-T connections alongside traditional 1G and 100M Ethernet, providing flexibility for mixed speed networks. Auto MDI/MDI-X avoids cabling issues and guest access controls help segment your network effectively.
When to choose it
Select this router if your setup requires wired 2.5G connectivity plus manageable security and you don’t need more than about 20,000 simultaneous connections. It’s a practical step-up without overshooting capacity or cost.
Specifications
| Ethernet LAN features | |
|---|---|
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Network | |
| Guest access | Yes |
| Port forwarding | Yes |
| Concurrent connections | 20000 |
| Auto MDI/MDI-X | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Switching capacity | 2 Gbit/s |
| Number of users | 10 user(s) |
| Throughput | 2 Gbit/s |
| Forwarding rate | 2000 Mpps |
| Policy-based routing | Yes |
| VLAN support | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Memory | |
| Flash memory | 512 MB |
| Internal memory | 1000 MB |
| Performance | |
| Concurrent connections | 20000 |
| Storage media | Flash |
| Flash memory | 512 MB |
| Internal memory | 1000 MB |
| Built-in processor | Yes |
| Processor frequency | 2000 MHz |
| WAN connection | |
| SFP WAN | No |
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| Management features | |
| Web-based management | Yes |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 5 |
| Protocols | |
| DHCP server | Yes |
| DHCP client | Yes |
| Technical details | |
| On/off switch | Yes |
| Rack mounting | No |
| Built-in processor | Yes |
| Processor frequency | 2000 MHz |
| Switching capacity | 2 Gbit/s |
| LED indicators | Power |
| Product colour | White |
| Package tare weight | 1.17 kg |
| Policy-based routing | Yes |
| Shipping (inner) case net weight | 1.48 kg |
| Shipping (inner) case height | 7.3 cm |
| Products per shipping (inner) case | 1 pc(s) |
| Products per pallet (sea) | 240 pc(s) |
| Products per pallet (air) | 240 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet height (sea) | 2.2 m |
| Pallet height (air) | 2.2 m |
| Master (outer) cases per pallet (sea) | 24 pc(s) |
| Master (outer) cases per pallet (air) | 24 pc(s) |
| Introduction year | 2024 |
| Introduction month | June |
| Warranty period | 2 year(s) |
| Security | |
| Guest access | Yes |
| Firewall | Yes |
| Security algorithms | WPA2 |
| VPN tunnels quantity | 5 |
| Packaging content | |
| Quick installation guide | Yes |
| AC adapter included | Yes |
| User Guide on CD-ROM | No |
| Quick start guide | Yes |
| Manual | Yes |
| Cables included | LAN (RJ-45) |
| Bundled software | License free Ransomware & Cybersecurity |
| Package type | Box |
| Software | |
| Bundled software | License free Ransomware & Cybersecurity |
| Features | |
| Storage media | Flash |
| Flash memory | 512 MB |
| Internal memory | 1000 MB |
| Built-in processor | Yes |
| Processor frequency | 2000 MHz |
| Processor manufacturer | Qualcomm |
| Design | |
| Housing material | Polycarbonate (PC) |
| Country of origin | Taiwan |
| Wall mountable | No |
| On/off switch | Yes |
| Rack mounting | No |
| LED indicators | Power |
| Product colour | White |
| Built-in display | No |
| Touchscreen | No |
| Power | |
| Power source type | DC |
| Output voltage | 12 V |
| Output current | 3 A |
| AC input voltage | 110 - 240 V |
| Power over Ethernet (PoE) | No |
| Redundant power supply (RPS) support | No |
| Power consumption (max) | 31 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 161.7 mm |
| Depth | 65 mm |
| Height | 229 mm |
| Weight | 707 g |
| Package width | 259 mm |
| Package depth | 266 mm |
| Package height | 73 mm |
| Package weight | 1.48 kg |
| Packaging data | |
| Quick installation guide | Yes |
| Package type | Box |
| Package tare weight | 1.17 kg |
| AC adapter included | Yes |
| Package width | 259 mm |
| Package depth | 266 mm |
| Package height | 73 mm |
| User Guide on CD-ROM | No |
| Quick start guide | Yes |
| Package weight | 1.48 kg |
| Manual | Yes |
| Cables included | LAN (RJ-45) |
| Bundled software | License free Ransomware & Cybersecurity |
| Logistics data | |
| Shipping (inner) case net weight | 1.48 kg |
| Shipping (inner) case height | 7.3 cm |
| Products per shipping (inner) case | 1 pc(s) |
| Products per pallet (sea) | 240 pc(s) |
| Products per pallet (air) | 240 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet height (sea) | 2.2 m |
| Pallet height (air) | 2.2 m |
| Master (outer) cases per pallet (sea) | 24 pc(s) |
| Master (outer) cases per pallet (air) | 24 pc(s) |
| Other features | |
| Switching capacity | 2 Gbit/s |
Check with Creative Systems to confirm this model matches your network size and connectivity needs before ordering.
