What it is
This StarTech.com switch allows control of up to three computers using a single keyboard, mouse, and monitor with DVI input, plus audio and USB 2.0 hub functionality.
Who it's for
Suitable for IT administrators or technical staff who need to manage multiple desktop systems efficiently from one console, including audio and USB peripherals.
Why it's good
It features hot-key switching, supports 1920x1200 resolution, and includes headphone and mic audio connections. USB ports allow sharing of devices across connected computers.
When to choose it
Pick this if you require smooth switching between up to three DVI-enabled computers with integrated audio support and USB hub capabilities in a desktop setup.
Specifications
| Ports & interfaces | |
|---|---|
| Console USB ports quantity | 4 |
| Console ports | 3.5mm headphone, 3.5mm mic, DVI-I, USB A |
| Number of microphone inputs | 3 |
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| Audio connections | Yes |
| Headphone outputs | 3 |
| DC-in jack | Yes |
| Performance | |
| Daisy chain | No |
| HD type | Full HD |
| Maximum resolution | 1920 x 1200 pixels |
| Number of users | 1 user(s) |
| Technical details | |
| Product colour | Black |
| Rack mounting | No |
| Number of users | 1 user(s) |
| LED indicators | Yes |
| Compliance certificates | CE, RoHS |
| Design | |
| Mean time between failures (MTBF) | 126397 h |
| Product colour | Black |
| Rack mounting | No |
| LED indicators | Yes |
| Display | |
| Built-in display | No |
| Power | |
| Input current | 0.8 A |
| Output current | 1.5 A |
| Power plug type | Type M |
| Compatible power plug types | EU, UK, US |
| Output voltage | 12 V |
| Power consumption (typical) | 18 W |
| Input voltage | 100 - 240 V |
| Video | |
| HD type | Full HD |
| Maximum resolution | 1920 x 1200 pixels |
| Sustainability | |
| Compliance certificates | CE, RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 199 mm |
| Depth | 160 mm |
| Height | 40 mm |
| Weight | 650 g |
| Package width | 242 mm |
| Package depth | 187 mm |
| Package height | 91 mm |
| Package weight | 1.1 kg |
| Packaging data | |
| Package width | 242 mm |
| Package depth | 187 mm |
| Package height | 91 mm |
| Package weight | 1.1 kg |
| Packaging content | |
| Rubber feet | Yes |
| Manual | Yes |
| Logistics data | |
| Master (outer) case width | 314 mm |
| Master (outer) case length | 399 mm |
| Master (outer) case height | 260 mm |
| Products per master (outer) case | 6 pc(s) |
| Harmonized System (HS) code | 85176200 |
