What it is
The Samsung VM55C-R is a 55-inch indoor signage display featuring an LCD panel with Full HD 1920x1080 resolution and an IPS panel for wide viewing angles, engineered for continuous 24/7 operation.
Who it's for
Intended for digital signage installations where a reliable, full HD display is needed around the clock in indoor environments.
Why it's good
Its 55-inch size combines good visibility with Samsung’s IPS technology, ensuring consistent colour and brightness across a wide viewing area, suitable for video walls or standalone displays.
When to choose it
Choose this model if you need a durable Full HD screen for indoor signage that operates continuously without compromise.
Specifications
| Display | |
|---|---|
| Display technology | LCD |
| Display diagonal | 139.7 cm (55") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Panel type | IPS |
| Aspect ratio | 16:9 |
| Pixel pitch | 0.63 x 0.63 mm |
| Display brightness | 500 cd/m² |
| Contrast ratio (typical) | 1100:1 |
| Response time | 8 s |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Colour gamut | 72% |
| Operating hours (hours/days) | 24/7 |
| Haze rate | 28% |
| Display diagonal (metric) | 138 cm |
| Pixel frequency | 78 MHz |
| Contrast ratio (dynamic) | 100000:1 |
| Horizontal scan range | 57.3 - 70 kHz |
| Vertical scan range | 47 - 63 Hz |
| Design | |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Bezel width (top) | 0.44 mm |
| Bezel width (side) | 0.44 mm |
| Bezel width (bottom) | 0.44 mm |
| Tiled bezel width | 0.44 mm |
| Wall mountable | Yes |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Product colour | Black |
| Bezel colour | Black |
| Frame material | Glossy |
| Ports & interfaces | |
| HDMI ports quantity | 2 |
| HDMI input ports quantity | 1 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| DisplayPorts quantity | 1 |
| DisplayPorts in | 1 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| USB port | Yes |
| USB ports quantity | 1 |
| HDCP version | 2.2 |
| HDCP | Yes |
| RS-232 output ports | 1 |
| RS-232 input ports | 1 |
| IR input ports quantity | 1 |
| Audio output | Yes |
| Audio input | Yes |
| HDMI version | 2.0 |
| DisplayPort version | 1.2 |
| Video out | Yes |
| Power | |
| Power consumption (typical) | 250 W |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 155 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Energy efficiency scale | A to G |
| Power consumption (sleep) | 0.5 W |
| Technical details | |
| Compliance certificates | CB, Federal Communications Commission (FCC) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Sustainability | |
| Sustainability compliance | Yes |
| Certification | FCC (USA) Part 15, Subpart B Class B CE (Europe) : EN 55032:2015+A11:2020 / EN 55035:2017+A11:2020 / EN IEC 61000-3-2:2019 / EN 61000-3-3:2013+A1:2019 VCCI (Japan) : VCCI-CISPR32 : 2015 KC (Korea) : KS C 9832 / KS C 9835 RCM (Australia/ Newzealand) : AS/N CB (Europe) : IEC62368-1/EN62368-1 CCC (China) : GB 4943.1-2011 (Singapore ) : PSB+IEC62368-1NOM (Mexico ) : Tunerless : NOM-019-SCFI-1998IRAM (Argentina ) : IRAM+IEC62368-1 SIRC (Saudi Arabia ) : SASO+IEC62368-1 BIS (India) : IEC60950-1 / IS13252KC (Kore |
| Weight & dimensions | |
| Width | 1211 mm |
| Depth | 69.9 mm |
| Height | 681.7 mm |
| Weight | 16.8 kg |
| Packaging data | |
| Package width | 1414 mm |
| Package depth | 257 mm |
| Package height | 844 mm |
| Package weight | 25.1 kg |
