What it is
The QNAP TS-453E is a 4-bay NAS server powered by an Intel Celeron J6412 processor with integrated Intel UHD Graphics, 8 GB RAM, and 4 GB flash memory. It supports a mix of HDD and SSD drives with four hot-swap bays.
Who it's for
This model suits small to medium-sized workgroups needing more storage capacity and flexibility than a 2-bay NAS offers, especially if multimedia processing or higher bandwidth is required.
Why it's good
The TS-453E allows online RAID migration and expansion, making it easier to adjust storage as your needs increase. Its extra bays and graphics support make it versatile for a wider range of applications.
When to choose it
Choose the TS-453E when you want a scalable NAS with up to four drives and the option to run multimedia tasks locally, but without moving up to enterprise-grade storage hardware.
Specifications
| Storage | |
|---|---|
| Total installed storage capacity | 0 TB |
| Online RAID migration | Yes |
| Online RAID expansion | Yes |
| Disk roaming | Yes |
| Bad block scan | Yes |
| Auto-rebuild | Yes |
| Storage drives installed | No |
| Installed storage drive type | No |
| Number of storage drives installed | 0 |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 4 |
| Hot-swap drive bays | Yes |
| RAID support | Yes |
| Supported file systems | FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Supported storage drive interfaces | M.2, Serial ATA III |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| Number of M.2 (M & B) slots | 2 |
| RAID rebuild | Yes |
| Processor | |
| Processor manufacturer | Intel |
| Processor threads | 4 |
| Processor boost frequency | 2.6 GHz |
| Processor frequency | 2 GHz |
| Processor family | Intel® Celeron® |
| Processor model | J6412 |
| Processor cores | 4 |
| Memory | |
| Internal memory | 8 GB |
| Maximum RAM supported | 8 GB |
| Flash memory | 4000 MB |
| Network | |
| Dynamic DNS (DDNS) | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Wake-on-LAN ready | Yes |
| Jumbo frames support | Yes |
| iSCSI support | Yes |
| DHCP server | Yes |
| Ports & interfaces | |
| USB port | Yes |
| HDMI version | 1.4b |
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Hard drive | |
| RAID support | Yes |
| Supported file systems | FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Design | |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| LED indicators | LAN, Power, Status |
| Chassis type | Tower |
| Technical details | |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Backup features | Cloud, iSCSI LUN |
| Product colour | Black |
| LED indicators | LAN, Power, Status |
| Chassis type | Tower |
| Buzzer | Yes |
| Number of fans | 1 fan(s) |
| Warranty period | 3 year(s) |
| Performance | |
| Built-in FTP server | Yes |
| System log | Yes |
| Share folder access right management | Yes |
| Share folder | 512 |
| S.M.A.R.T. support | Yes |
| Password authentication | Yes |
| Hot spare | Yes |
| Disk scan | Yes |
| Browser supported | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
| Backup button | Yes |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Backup features | Cloud, iSCSI LUN |
| On/off switch | Yes |
| Windows operating systems supported | Windows 10, Windows 8, Windows 7, Windows 11 |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Other operating systems supported | Solaris 10 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina |
| Linux operating systems supported | Ubuntu 14.04 |
| Security algorithms | FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH |
| Reset button | Yes |
| Operating system version | 5.0.1 |
| Operating system installed | QNAP QTS |
| Management protocols | SNMP V2/V3 |
| Buzzer | Yes |
| Access Control List (ACL) | Yes |
| Snapshot | Yes |
| USB copy function | Yes |
| Cooling | |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Fan voltage | 12 V |
| Number of fans | 1 fan(s) |
| Security | |
| Security algorithms | FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH |
| Access Control List (ACL) | Yes |
| Software | |
| Windows operating systems supported | Windows 10, Windows 8, Windows 7, Windows 11 |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Other operating systems supported | Solaris 10 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina |
| Linux operating systems supported | Ubuntu 14.04 |
| Operating system version | 5.0.1 |
| Operating system installed | QNAP QTS |
| Management features | |
| On/off switch | Yes |
| Reset button | Yes |
| Management protocols | SNMP V2/V3 |
| Power | |
| Power supply location | External |
| Power supply unit (PSU) capacity | 90 W |
| Fan voltage | 12 V |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 33.88 W |
| Power consumption (sleep) | 15.78 W |
| Number of power supply units | 1 |
| External power adapter | Yes |
| Weight & dimensions | |
| Package width | 307 mm |
| Package depth | 520 mm |
| Package height | 320 mm |
| Width | 160.2 mm |
| Depth | 220.5 mm |
| Height | 168.5 mm |
| Weight | 3 kg |
| Package weight | 3.61 kg |
| Packaging content | |
| Package type | Box |
| External power adapter | Yes |
| Cables included | AC, LAN (RJ-45) |
| Power cables quantity | 1 |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 8, Windows 7, Windows 11 |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Other operating systems supported | Solaris 10 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina |
| Linux operating systems supported | Ubuntu 14.04 |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Packaging data | |
| Package width | 307 mm |
| Package depth | 520 mm |
| Package height | 320 mm |
| Package weight | 3.61 kg |
| Cables included | AC, LAN (RJ-45) |
| Other features | |
| Warranty period | 3 year(s) |
Get in touch with Creative Systems to verify drive compatibility, stock availability, and suitability for your setup before ordering.
